Vietnam 800t/d Graphite Mineral Processing Plant

The Vietnam 800t/d graphite mineral processing plant was an EPC+M+O project. The major mineral was graphite granulite, while the secondary one was graphite schist. The major beneficial mineral was medium flaky graphite which had a much better ability of beneficiation.

Xinhai Solution Main Equipment Project Result Project Site

CHAT

MESSAGE

Xinhai Solution

Two-stage closed-circuit crushing-one-stage closed-circuit grinding and classification-flotation process of one-stage roughing, two-stage scavenging and ten-stage concentration.

The mineral processing test showed that graphite concentrates could be produced through nine-stage grinding, one-stage roughing, one-stage scavenging and nine-stage concentration, with a yield of 14.20%, a fixed carbon content of 92.30% and a recovery of 87.91%.

To obtain high-carbon graphite concentrates, the graphite concentrates were treated by wet screening. As a result, the yield and fixed carbon content of -140 mesh concentrates were 3.68% and 95% respectively; those of -140 mesh concentrates were 10.72% and 91.46% respectively.

Main Equipment

Electromagnetic Vibrating Feeder

A feeder with simple structure and suitable for non-sticky materials

Belt Feeder

A belt feeder with heave pressure bearing

SF Flotation Cell

SF flotation cell is a mechanical agitation type flotation machine with slurry suction and air suction.

JJF Flotation, Wemco Flotation

JJF flotation cell is a air self-suction mechanical stirring floatation cell without slurry suction (Referring to the design of USA wemco flotation machine)

Project Result

Thanks to sound technological process and simple reagent system, advanced indices were achieved for the project. The recovery of graphite concentrates was up to 92%, promising an annual profit of $48 million.
