Heilongjiang 500tpd Lead and Zinc Mineral Processing Plant

The main metallic minerals of this project were sphalerite, galena, argentite, etc. The main gangue minerals were quartz, calcite and dolomite. The content of Pb, Zn and Ag in raw ore was 2.45%, 8.36% and 150g/t respectively.

Xinhai Solution Main Equipment Project Result Project Site

Xinhai Solution

01

When the grinding particle size was -200 mesh (74%), the differential flotation process (zinc inhibition first and lead flotation then) was adopted, in which the lead system adopted one-stage roughing, one-stage scavenging and two-stage concentration.

Main Equipment

SF Flotation Cell

SF flotation cell is a mechanical agitation type with slurry suction and air suction.
KYF Air Inflation Flotation Cell

An air-inflation mechanical agitation flotation cell without slurry suction (This type of cell is designed referring to Finland Autoquenpu OK flotation cell).
BF Flotation Cell

A mechanical agitation type floatation cell unit with air suction and combination of slurry suction/no slurry suction
XCF Air Inflation Flotation Cell

An air inflation mechanical agitation flotation cell with slurry suction（as suction cell of KYF flotation cell).

Project Result

The yield of lead concentrate was 4.12%, the grade of lead was 56.73%, and the recovery rate was 91.62%. The yield of zinc concentrate was 15.65%, the zinc grade was 48.53%, and the recovery rate was 90.42%. the silver was mainly concentrated in the lead concentrate, which contained 2864.9g/t silver, and the recovery of silver was 80.29%.
